Drive-Rite Height Sensor
Product Code: DR.35.011405
Specifications
| Part Number | DR.35.011405 |
| Height Sensor Type | Universal |
| Cross Reference Number | IR.400.1405 |
| Mounting Holes | 2x M5 holes |
| Sensor Range | ±37° |
| Arm Length Max | 67 mm |
| Arm Length Centre to Centre | 50 mm |
| Protection Rating |
IP66* *dependent on connector |
| Operating Temperature | -40°C -> 125°C |
Special Notes
The Drive-Rite Height Sensor is supplied with a bult in rotating arm.
Contact Drive-Rite directly for information on the range of 'arm extensions' and Linkages.
