4 Corner ECU - Programmed without a Horizon Levelling Sensor

Product Code: DR.32.014100

Print

Specifications

Part Number DR.32.014100
ECU Type 4 Corner
Cross Reference Number -
Mounting Holes 4x M5 holes
Maximum Width 165 mm
Maximum Height 64 mm
Maximum Length 130 mm
Protection Rating IP67
Operating Temperature -40°C -> 85°C



Special Notes

This ECU is pre-programmed to accommodate AMK DR.12.011201 compressors and a DR.33.011025 '4 Corner' valve block.

If a different compressor or valve block is installed contact Drive-Rite before use.

Image for 4 Corner ECU - Programmed without a Horizon Levelling Sensor


Click thumbnail to view detailed image.

IntelliRide is a fully automatic, Electronically Controlled Air Suspension (ECAS) System. When fitted the system provides comfort while maintaining a programmed ride height irrespective of the load. Multiple vehicle heights are available at the push of a button.

The Electronic Control Unit (ECU) is the centre of the ECAS systems. The ECU can be programmed to precisely control the InteliRide kit and give state of the art precision.
