Air Compressor - Ultimate Duty
Product Code: DR.12.019286
Specifications
| Compressor Type | Firestone |
| Part # | DR.12.019286 |
| Integrated Dryer | No |
| Integrated Quick Release | No |
Electrical Data
| Operating Voltage Range | 9 - 16 V DC |
| Max. AMP Draw | 19 Amps |
| Duty Cycle | 100% |
| Temperature Range | -40 degC to 70 degC |
Pneumatic Data
| Pressure Control | 10.3 Bar (150 psi) |
| Volume Fill Time (RT) | 0-10 Bar (0-145psi) in 285 sec for 7.5 litres (2.5 gallon) |
Other Data
| Mounting Position | Multi-axis |
| Weight | 3.88 kg (8.55 lbs) |
| Flow Data | See Spec Image |
| Tube Connection | 1/4" tube |
| Standard Filter Kit | DR.12.019129 |
Special Notes
Use with up to 18.9 litres (5 gallon) Reservoir
Click thumbnail to view detailed image.
