Air Compressor - Medium Duty

Product Code: DR.12.019271

Print

Specifications

Compressor Type Drive-Rite
Part # DR.12.019271
Integrated Dryer No
Integrated Quick Release No



Electrical Data

Operating Voltage Range 9 - 16 V DC
Max. AMP Draw 14 Amps
Duty Cycle 15%
Temperature Range -40 degC to 70 degC

Pneumatic Data

Pressure Control 9 Bar (130 psi)
Volume Fill Time (RT) 0-120psi (8.27 bar) in 120 sec for 1 gallon

Other Data

Mounting Position Multi-axis
Weight 1.56 kg (3.45 lbs)
Flow Data See Spec Image
Tube Connection 1/4" tube



Special Notes

  • Use with up to 3.75 litres (1 gallon) Reservoir
  • Removable Mounting Bracket

Image for Air Compressor - Medium Duty


Click thumbnail to view detailed image.

Medium Duty Compressor

The Medium Duty Firestone compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.

The system offers a dependable, lasting service for moderate use applications.The DR.12.019271 compressor is designed to be as compact as possible.

  • The bracket for this Compressor is removable for ease of use.
  • It has an air intake built into the head of the compressor compact.
