Air Compressor - Basic

Product Code: DR.12.011260

Print

Specifications

Compressor Type Drive-Rite
Part # DR.12.011260
Integrated Dryer No
Integrated Quick Release No

Electrical Data

Operating Voltage Range 9 - 16 V DC
Max. AMP Draw 12 Amps
Duty Cycle 15%
Temperature Range -40 degC to 70 degC

Pneumatic Data

Pressure Control 100psi
Volume Fill Time (RT) 0-80psi (5.5 bar) in 102 sec for 1 gallon

Other Data

Mounting Position Multi-axis
Weight 0.5kg (1.1lbs)
Flow Data See Spec Image
Tube Connection 1/4" tube barbed fitting



Special Notes

Not for use with Air Reservoir.

Image for Air Compressor - Basic


Click thumbnail to view detailed image.

Basic Compressor

The Drive-Rite Basic compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.

The system offers a dependable, lasting service for moderate use applications.

These compressors are designed to be connected directly to Drive-Rite Semi-Air kits. So with this in mind they they have a built in one way valve to protect the compressor from pressure surges from the kit. Increasing the lifespan of the compressor.
